Fife SE-31 Intrinsically Safe Ultrasonic Sensor
Fife SE-31 Intrinsically Safe Ultrasonic Sensor - Image 2
Fife SE-31 Intrinsically Safe Ultrasonic Sensor - Image 3

Fife SE-31 Intrinsically Safe Ultrasonic Sensor

The SE-31-IS Ultrasonic Sensor is specifically designed to perform in hazardous locations, Class I, Division 1, Groups C & D. Ideal for guiding thin or clear films, as well as most opaque webs, this sensor is fully certified under UL, cUL (US and Canada), and CENELEC (Europe).

The SE-31-IS has control range of 7.62 mm (0.3 inch), a sensing gap of 50.8 mm (2.0 inches), and requires the same 12 VDC power supply as most other Fife sensors. The maximum sensor voltage and current is protected through a safety barrier
located outside of the hazardous area. Maximum cable length from the sensor to the controller is 4.19 m (165 feet).

Categories: , , ,

Description

FIFE SE-31 INTRINSICALLY SAFE ULTRASONIC SENSOR SPECIFICATIONS

[tabbed_section style=”default” alignment=”left” spacing=”default” tab_color=”Accent-Color”][tab icon_family=”none” title=”Imperial” id=”1590493157716-0″ tab_id=”1590493157717-9″]
  • Linearity5% nominal maximum error
  • Plane Change5% nominal maximum error
  • Power Requirements+12 VDC
  • Output Rate0 to 10 mA
  • Update Rate3 ms
  • Weight432.1 grams
  • Temperature Range5 to 60˚ C
[/tab][tab icon_family=”none” title=”Metric” id=”1590493157743-5″ tab_id=”1590493157743-3″]
  • Linearity5% nominal maximum error
  • Plane Change5% nominal maximum error
  • Power Requirements+12 VDC
  • Output Rate0 to 10 mA
  • Update Rate3 ms
  • Weight432.1 grams
  • Temperature Range5 to 60˚ C
[/tab][/tabbed_section]
