Stainless Steel

Live Shaft Steel Idlers are often ideal whenever the web or the environment challenges roll integrity or performance.

Live shaft idlers have several application advantages:

Highly Corrosive Environments
High moisture environments can rust and corrode steel idlers. Webs made of PVC materials can form hydrochloric acid. Certain processes require the use of caustic solutions. All these can damage steel and impact the performance of standard steel idlers. For more aggressive environments, other stainless steel grades are available.

Elevated Temperature
Webex Live Shaft Stainless Steel Idlers can handle substantially elevated temperatures with proper venting. This makes Live Shafts ideal in ovens where an elevated temperature or solvent atmosphere would quickly destroy dead shaft roll bearings.

Harsh Environments
By positioning the roller bearings out of the immediate web path, exposure to process contaminates is minimized. That’s why Live Shaft rolls are often ideal in applications where chemicals, dust or vapors commonly destroy dead shaft roll bearings. For greater wear-resistance, Stainless Steel Idlers can be readily plated with plasma coating, nickel or chrome.

Description

LIVE SHAFT STAINLESS STEEL IDLER ROLLS SPECIFICATIONS

[tabbed_section style=”default” alignment=”left” spacing=”default” tab_color=”Accent-Color”][tab icon_family=”none” title=”Imperial” id=”1590403564953-1″ tab_id=”1590403564955-5″]

Material	Type 304 stainless steel tubing machined for minimum stock removal
Finish	32 Ra
Straightness	within the greater of 0.002 inch or 0.0005 inch/ft. of length
Journal Material	Type 300 series stainless steel
LCR-300 SPECIFICATIONS
Nominal Roll Diameter	3 inches
Wall Thickness	0.25 inches
Dynamically Balanced at	1,500 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 72 inch within 0.005 inch
LCR-400 SPECIFICATIONS
Nominal Roll Diameter	4 inches
Wall Thickness	0.25 inches
Dynamically Balanced at	1,500 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch
LCR-500 SPECIFICATIONS
Nominal Roll Diameter	5 inches
Wall Thickness	0.25 inches
Dynamically Balanced at	2,000 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch face length to 96 inch within 0.008 inch
LCR-600 SPECIFICATIONS
Nominal Roll Diameter	6 inches
Wall Thickness	0.375 inches
Dynamically Balanced at	2,000 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch face length to 108 inch within 0.008 inch

[/tab][tab icon_family=”none” title=”Metric” id=”1590403564974-3″ tab_id=”1590403564974-8″]

Material	Type 304 stainless steel tubing machined for minimum stock removal
Finish	32 Ra
Straightness	within the greater of 0.002 inch or 0.0005 inch/ft. of length
Journal Material	Type 300 series stainless steel
LCR-300 SPECIFICATIONS
Nominal Roll Diameter	76.2 mm
Wall Thickness	6.35 mm
Dynamically Balanced at	1,500 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 72 inch within 0.005 inch
LCR-400 SPECIFICATIONS
Nominal Roll Diameter	101.6 mm
Wall Thickness	6.35 mm
Dynamically Balanced at	1,500 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch
LCR-500 SPECIFICATIONS
Nominal Roll Diameter	127 mm
Wall Thickness	6.35 mm
Dynamically Balanced at	2,000 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch face length to 96 inch within 0.008 inch
LCR-600 SPECIFICATIONS
Nominal Roll Diameter	152.4 mm
Wall Thickness	9.53 mm
Dynamically Balanced at	2,000 fpm
Journal Runout to roll O.D. within	face length to 48 inch within 0.004 inch face length to 80 inch within 0.006 inch face length to 108 inch within 0.008 inch
