Steel

Live Shaft Steel Idlers are often ideal whenever the web or the environment challenges roll integrity or performance.

Live shaft idlers have several application advantages:

High Loads
Self-aligning pillow blocks and flange bearings used to mount live shaft idlers are capable of handling higher loads than comparable dead shaft idlers using rigid bearings.

Elevated Temperature
Webex Live Shaft Steel Idlers can handle substantially elevated temperatures with proper venting. This makes Live Shafts ideal in ovens where an elevated temperature or solvent atmosphere would quickly destroy dead shaft roll bearings.

Any idler intended for use in elevated temperatures must have proper venting to avoid explosion. Be sure you identify such applications upon ordering.

Harsh Environments
By positioning the roller bearings out of the immediate web path, exposure to process contaminates is minimized. That’s why Live Shaft rolls are often ideal in applications where chemicals, dust or vapors commonly destroy dead shaft roll bearings.

Description

WEBEX LIVE SHAFT STEEL SPECIFICATIONS

[tabbed_section style=”default” alignment=”left” spacing=”default” tab_color=”Accent-Color”][tab icon_family=”none” title=”Imperial” id=”1590403429043-9″ tab_id=”1590403429044-5″]

Material	1026 carbon steel tubing machined for minimum stock removal
Finish	32 Ra
Straightness	within the greater of 0.002 inch or 0.0005 inch/ft. of length
Journal Material	1018 carbon steel
LSS-300 SPECIFICATIONS
Nominal Roll Diameter	3 inches
Wall Thickness	0.1875 inches
Dynamically Balanced at	1,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 72 inch within 0.004 inch
LSS-400 SPECIFICATIONS
Nominal Roll Diameter	4 inches
Wall Thickness	0.25 inch
Dynamically Balanced at	1,500 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch
LSS-500 SPECIFICATIONS
Nominal Roll Diameter	5 inches
Wall Thickness	0.3125 inches
Dynamically Balanced at	2,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch face length to 106 inch within 0.005 inch
LSS-600 SPECIFICATIONS
Nominal Roll Diameter	6 inches
Wall Thickness	0.375 inches
Dynamically Balanced at	2,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch face length to 106 inch within 0.005 inch

[/tab][tab icon_family=”none” title=”Metric” id=”1590403429108-4″ tab_id=”1590403429109-1″]

Material	1026 carbon steel tubing machined for minimum stock removal
Finish	32 Ra
Straightness	within the greater of 0.002 inch or 0.0005 inch/ft. of length
Journal Material	1018 carbon steel
LSS-300 SPECIFICATIONS
Nominal Roll Diameter	76.2 mm
Wall Thickness	4.76 mm
Dynamically Balanced at	1,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 72 inch within 0.004 inch
LSS-400 SPECIFICATIONS
Nominal Roll Diameter	101.6 mm
Wall Thickness	0.25 inch
Dynamically Balanced at	1,500 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch
LSS-500 SPECIFICATIONS
Nominal Roll Diameter	127 mm
Wall Thickness	7.94 mm
Dynamically Balanced at	2,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch face length to 106 inch within 0.005 inch
LSS-600 SPECIFICATIONS
Nominal Roll Diameter	152.4 mm
Wall Thickness	9.53 mm
Dynamically Balanced at	2,000 FPM
Journal Runout to roll O.D. within	face length to 48 inch within 0.002 inch face length to 80 inch within 0.004 inch face length to 106 inch within 0.005 inch
